For over two decades, Shiraz Flanges has stood as a trusted name in Safat, Kuwait, specializing in the supply of high-quality industrial components. Our commitment to excellence is perfectly embodied in our DIN 2631 PN6 Weld Neck Flanges. Crafted with precision, these flanges are the go-to choice for professionals seeking reliability in high-pressure piping systems. We understand that in the heart of Kuwait’s industry, durability isn’t just a feature—it’s a necessity, and we deliver on that promise with every piece.
Our DIN 2631 PN6 Weld Neck Flanges are forged from superior materials, typically fine-grained steel, to meet rigorous standards. They possess excellent mechanical properties, including a minimum tensile strength of 400 MPa and a minimum yield strength of 235 MPa. This robust construction ensures superior performance under pressure, making them capable of handling demanding conditions. The precise engineering guarantees a perfect fit and long-lasting service life in your critical applications.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Pipe | Flange | Neck | Raised face | Screws | Weight | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (7,85 Kg/dm3) | ||||||||||||||||
| Rated | d1 | D | b | k | h1 | d3 | s | r | h2 | d4 | f | Holes | Thread | d2 | Kg | |
| Diameter | ISO Series | DIN Series | ||||||||||||||
| 15 | – | 20 | 80 | 12 | 55 | 30 | 28 | 2 | 4 | 6 | 40 | 2 | 4 | M 10 | 11 | 0,392 |
| 21,3 | – | 30 | ||||||||||||||
| 20 | – | 25 | 90 | 14 | 65 | 32 | 35 | 2,3 | 4 | 6 | 50 | 2 | 4 | M 10 | 11 | 0,592 |
| 26,9 | – | 38 | ||||||||||||||
| 25 | – | 30 | 100 | 14 | 75 | 35 | 40 | 2,6 | 4 | 6 | 60 | 2 | 4 | M 10 | 11 | 0,747 |
| 33,7 | – | 42 | ||||||||||||||
| 32 | – | 38 | 120 | 14 | 90 | 35 | 50 | 2,6 | 6 | 6 | 70 | 2 | 4 | M 12 | 14 | 1,05 |
| 42,4 | – | 55 | ||||||||||||||
| 40 | – | 44,5 | 130 | 14 | 100 | 38 | 58 | 2,6 | 6 | 7 | 80 | 3 | 4 | M 12 | 14 | 1,18 |
| 48,3 | – | 62 | ||||||||||||||
| 50 | – | 57 | 140 | 14 | 110 | 38 | 70 | 2,9 | 6 | 8 | 90 | 3 | 4 | M 12 | 14 | 1,34 |
| 60,3 | – | 74 | ||||||||||||||
| 65 | 76,1 | – | 160 | 14 | 130 | 38 | 88 | 2,9 | 6 | 9 | 110 | 3 | 4 | M 12 | 14 | 1,67 |
| 80 | 88,9 | – | 190 | 16 | 150 | 42 | 102 | 3,2 | 8 | 10 | 128 | 3 | 4 | M 16 | 18 | 2,71 |
| 100 | – | 108 | 210 | 16 | 170 | 45 | 122 | 3,6 | 8 | 10 | 148 | 3 | 4 | M 16 | 18 | 3,24 |
| 114,3 | 130 | |||||||||||||||
| 125 | – | 133 | 240 | 18 | 200 | 48 | 148 | 4 | 8 | 10 | 178 | 3 | 8 | M 16 | 18 | 4,49 |
| 139,7 | – | 155 | ||||||||||||||
| 150 | – | 159 | 265 | 18 | 225 | 48 | 172 | 4,5 | 10 | 12 | 202 | 3 | 8 | M 16 | 18 | 5,15 |
| 168,3 | – | 184 | ||||||||||||||
| 200 | 219,1 | – | 320 | 20 | 280 | 55 | 236 | 5,9 | 10 | 15 | 258 | 3 | 8 | M 16 | 18 | 7,78 |
| 250 | – | 267 | 375 | 22 | 335 | 60 | 282 | 6,3 | 12 | 15 | 312 | 3 | 12 | M 16 | 18 | 10,8 |
| 273 | – | 290 | ||||||||||||||
| 300 | 323,9 | – | 440 | 22 | 395 | 62 | 342 | 7,1 | 15 | 15 | 365 | 4 | 12 | M 20 | 22 | 14 |
| 350 | 355,6 | – | 490 | 22 | 445 | 62 | 385 | 7,1 | 12 | 15 | 415 | 4 | 12 | M 20 | 22 | 18,5 |
| – | 368 | 16,7 | ||||||||||||||
| 400 | 406,4 | – | 540 | 22 | 495 | 65 | 438 | 7,1 | 12 | 15 | 465 | 4 | 16 | M 20 | 22 | 21,2 |
| – | 419 | 19 | ||||||||||||||
| 500 | 508 | – | 645 | 24 | 600 | 68 | 538 | 7,1 | 12 | 15 | 570 | 4 | 20 | M 20 | 22 | 28,6 |
| 600 | 610 | – | 755 | 24 | 705 | 70 | 640 | 7,1 | 12 | 16 | 670 | 5 | 20 | M 24 | 26 | 31,5 |
| 700 | 711 | – | 860 | 24 | 810 | 70 | 740 | 7,1 | 12 | 16 | 775 | 5 | 24 | M 24 | 26 | 37,4 |
| 800 | 813 | – | 975 | 24 | 920 | 70 | 842 | 7,1 | 12 | 16 | 880 | 5 | 24 | M 27 | 30 | 46,1 |
| 900 | 914 | – | 1075 | 26 | 1020 | 70 | 942 | 7,1 | 12 | 16 | 980 | 5 | 24 | M 27 | 30 | 55,6 |
| 1000 | 1016 | – | 1175 | 26 | 1120 | 70 | 1045 | 7,1 | 16 | 16 | 1080 | 5 | 28 | M 27 | 30 | 61,9 |
Shiraz Flanges, a leading supplier in Safat, Kuwait, offers an extensive selection of DIN 2631 PN6 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2631 PN6 Weld Neck Flanges are primarily used in low-pressure piping systems across industries such as oil and gas, petrochemical, water treatment, and HVAC. Their design allows for secure, leak-proof connections and minimizes stress at the base, making them ideal for systems where temperature and pressure may fluctuate mildly. These flanges are commonly installed in pipelines, pumps, and valves, providing stability and alignment. Their durability and precise fit make them essential for ensuring efficient flow and system integrity in low-pressure applications.
Yes, we offer custom sizes for DIN 2631 PN6 Weld Neck Flanges to meet specific project needs. Our team at Shiraz Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@shirazflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| Nickel Alloy DIN 2631 PN6 Welding Neck Flange | Mild Steel DIN 2631 PN6 Weld Neck Flange |
| Carbon Steel DIN 2631 PN6 Welding Neck Flange | DIN 2631 PN6 Weld Neck RF Flange Supplier in Kuwait |
| DIN 2631 PN6 Weld Neck Flange Dimensions | Raised Face DIN 2631 PN6 Weld Neck Flange Manufacturer |
| 18 inch DIN 2631 PN6 Carbon Steel Weld Neck Flange | DIN 2631 PN6 Weld Neck Flange Dimensions in mm |
| Alloy Steel DIN 2631 PN6 Welding Neck Flanges | Copper Nickel DIN 2631 PN6 Weld Neck Flanges at Best Price |
| DIN 2631 PN6 Welding Neck FF Flange Supplier | Suppliers of DIN 2631 PN6 Weld Neck Flange |
| German Standard DIN 2631 PN6 Weld Neck Flanges | DIN 2631 PN6 Weld Neck Flange Supplier in Kuwait
|
| DIN 2631 PN6 Weld Neck Flange Manufacturer | Flat Face DIN 2631 PN6 Weld Neck Flange Manufacturer |
| DIN 2631 PN6 WNRF Flange Stockist in Kuwait | Raised Faced DIN 2631 PN6 welding-neck flanges Dealer in Kuwait |
| Stainless Steel DIN 2631 PN6 Weld Neck Flange | ASTM B564 Raised Faced DIN 2631 PN6 Weld Neck Flanges |
| DIN 2631 PN6 WNRF Flange Exporter | DIN 2631 PN6 Weld Neck Flange Pressure Ratings |
| Raised Face DIN 2631 PN6 Weld Neck Plate Flanges | Titanium DIN 2631 PN6 Welding Neck Flanges |
| DIN 2631 PN6 WNRF Flanges Supplier in Hawalli | Alloy Steel DIN 2631 PN6 Weld Neck Flanges Manufacturer in Kuwait |
| DIN 2631 PN6 Weld Neck Pipe Flanges Supplier in Jahra | Duplex Steel DIN 2631 PN6 Weld Neck Flanges |
| 4 inch Stainless Steel DIN 2631 PN6 Weld Neck Flange | DIN 2631 PN6 Weld Neck RF Flanges Stockholder |
| DIN 2631 PN6 Welding Neck Flanges Supplier in Safat | MS DIN 2631 PN6 Weld Neck Flange |
| 30 inch DIN 2631 PN6 Weld Neck Flange Dealer | Raised Face DIN 2631 PN6 Weld Neck Flanges Manufacturer |
| 8 Inch DIN 2631 PN6 Welding Neck Pipe Flanges | DIN 2631 PN6 Weld Neck Flanges Stockist |
| Carbon Steel Raised Face DIN 2631 PN6 Weld Neck Flange Stockist | Duplex Steel DIN 2631 PN6 WNRF Flanges Supplier in Safat |
| ASME SA105N Raised Faced DIN 2631 PN6 Weld Neck Flanges | 18 inch Carbon Steel DIN 2631 PN6 Weld Neck Flange |
| DIN 2631 PN6 Weld Neck Pipe Flanges Wholesaler | DIN 2631 PN6 WNRF Flanges Supplier |
| DIN 2631 PN6 Large Diameter Weld Neck Flange | 30 Inch DIN 2631 PN6 Weld Neck Pipe Flange Dimensions |
| DIN 2631 PN6 WNRF Flanges Distributor in Safat | Flat Face DIN 2631 PN6 Weld Neck Flanges Exporter |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
